DJI Mini 5 Pro

Takeoff Weight

249.9 g

^{‌Product weight may vary due to differences in batch materials and other factors. The actual weight is approximately 249.9 g ± 4 g and is subject to the actual product. Before flying with the Intelligent Flight Battery or the Intelligent Flight Battery Plus, check and comply with local laws and regulations to confirm whether registration or an exam is required.
The Intelligent Flight Battery Plus is not sold in Europe.}

Dimensions

Folded (without propellers): 157×95×68 mm (L×W×H)
Unfolded (with propellers): 304×380×91 mm (L×W×H)

Max Ascent Speed

10 m/s (S Mode)
5 m/s (N Mode)
5 m/s (C Mode)

Max Descent Speed

8 m/s (S Mode, using DJI Mini 5 Pro Intelligent Flight Battery Plus*)
6 m/s (S Mode, using DJI Mini 5 Pro Intelligent Flight Battery)
5 m/s (N Mode)
5 m/s (C Mode)

^{* The Intelligent Flight Battery Plus is not sold in Europe.}

Max Horizontal Speed

19 m/s* (S Mode, using DJI Mini 5 Pro Intelligent Flight Battery Plus**)
18 m/s* (S Mode, using DJI Mini 5 Pro Intelligent Flight Battery)
15 m/s*** (tracking status)

^{* Measured in a wind tunnel test environment when taking off from an altitude of 0 meter and ascending vertically to a height of 1.5 meters above the ground in Sport mode, and is for reference only. Always pay attention to reminders on the camera view during your flight.
** The Intelligent Flight Battery Plus is not sold in Europe.
*** Measured in an open, windless test environment with the drone taking off from an altitude of 0 meters.}

Max Takeoff Altitude

6000 m (using DJI Mini 5 Pro Intelligent Flight Battery)
4500 m (using DJI Mini 5 Pro Intelligent Flight Battery Plus*)

^{* The Intelligent Flight Battery Plus is not sold in Europe.}

Max Flight Time

36 minutes (using DJI Mini 5 Pro Intelligent Flight Battery)

^{Measured by the aircraft flying forward at a constant speed of 21.6 kph in a windless environment at sea level, with Obstacle Avoidance Action set to Brake, in photo mode, until forced landing due to low voltage. Data is for reference only. Always pay attention to reminders in the app during your flight.}

52 minutes (using DJI Mini 5 Pro Intelligent Flight Battery Plus*)

<sup>Measured by the aircraft flying forward at a constant speed of 25.2 kph in a windless environment at sea level, with Obstacle Avoidance Action set to Brake, in photo mode, until forced landing due to low voltage. Data is for reference only. Always pay attention to reminders in the app during your flight.
* The Intelligent Flight Battery Plus is not sold in Europe.</sup>

Typical Flight Time

21 minutes (using DJI Mini 5 Pro Intelligent Flight Battery)
33 minutes (using DJI Mini 5 Pro Intelligent Flight Battery Plus*)

<sup>Measured at sea level in a breezy environment, with the aircraft taking off with a fully charged battery, Obstacle Avoidance Action set to Brake, and the camera set to record at 4K/60fps. After takeoff, the aircraft ascends to 120  m and flies forward 1 km at 15 m/s before recording begins (about 15 minutes of recording with the Intelligent Flight Battery, and about 20 minutes with the Intelligent Flight Battery Plus). During recording, the aircraft adjusts gimbal movements and its flight position at speeds of up to 10 m/s over a total distance of approximately 2 km, while hovering for the remaining time. The aircraft hovers until a RTH reminder appears, then initiates auto RTH and completes a safe landing. Data is for reference only. Always pay attention to reminders in the app during your flight.
* The Intelligent Flight Battery Plus is not sold in Europe.</sup>

Max Flight Distance

21 km (using DJI Mini 5 Pro Intelligent Flight Battery)
32 km (using DJI Mini 5 Pro Intelligent Flight Battery Plus*)

<sup>Measured by the aircraft flying forward at a constant speed of 39.6 kph in a windless environment at sea level, with Obstacle Avoidance Action set to Brake, in photo mode, until forced landing due to low voltage. Data is for reference only. Always pay attention to reminders in the app during your flight.
* The Intelligent Flight Battery Plus is not sold in Europe.</sup>

Max Wind Speed Resistance

12 m/s

Max Pitch Angle

38°

Operating Temperature

-10° to 40° C (14° to 104° F)

Global Navigation Satellite System

GPS + Galileo + BeiDou

Hovering Accuracy Range

Vertical:
±0.1 m (with vision positioning)
±0.5 m (with satellite positioning)

Horizontal:
±0.3 m (with vision positioning)
±0.5 m (with satellite positioning)

Internal Storage

42 GB

Class

C0 (EU), with the option to apply for C1 (EU) in the DJI Fly app.

Image Sensor

1-inch CMOS, 50MP Effective Pixels

Lens

FOV: 84°
Format Equivalent: 24 mm
Aperture: f/1.8
Focus: 0.5 m to ∞

ISO Range

Video
Normal:
100-12800 (Normal)
100-3200 (D-Log M)
100-3200 (HLG)
Slow Motion:
100-6400 (Normal)
100-3200 (D-Log M)
100-3200 (HLG)

100-6400 (12 MP)
100-3200 (50 MP)

Shutter Speed

12MP Photo: 1/8000-2 s (2.5-8 s for simulated long exposure)
50MP Photo: 1/8000-2 s

Max Image Size

8192×6144

Still Photography Modes

Single Shot: 12 MP and 50 MP
Burst Shooting: 12 MP, 3/5/7 frames; 50 MP, 3/5 frames
Automatic Exposure Bracketing (AEB): 12 MP, 3/5/7 frames; 50 MP, 3/5 frames at 0.7 EV step
Timed: 12 MP, 2/3/5/7/10/15/20/30/60 s; 50 MP, 5/7/10/15/20/30/60 s

Photo Format

JPEG/DNG (RAW)

Video Resolution

H.264/H.265
4K: 3840×2160@24/25/30/48/50/60/120*fps
FHD: 1920×1080@24/25/30/48/50/60/120*/240*fps

^{* Recording frame rates. The corresponding video plays as a slow-motion video. Slow-motion videos and 4K video recordings only support H.265 encoding.}

Video Format

MP4 (MPEG-4 AVC/H.264, HEVC/H.265)

Max Video Bitrate

H.264/H.265: 130 Mbps

^{* When shooting 4K/120fps video in D-Log M mode with DJI Mini 5 Pro, the video encoding bitrate can reach up to 130Mbps, corresponding to a video stream frame rate of 120fps. However, since slow-motion video files are encapsulated at 30fps, the video length displayed on the player is four times the recording duration, and the bitrate of the parsed encapsulated file is approximately one-fourth of the original encoding bitrate.}

Supported File System

exFAT

Color Mode and Sampling Method

Normal (FHD):
8-bit 4:2:0 (H.264)

Normal (FHD/4K):
10-bit 4:2:0 (H.265)

HLG/D-Log M:
10-bit 4:2:0 (H.265)

Digital Zoom

12MP Photo: 1-3x
4K: 1-3x
FHD: 1-4x

Stabilization

3-axis mechanical gimbal (tilt, roll, pan)

Mechanical Range

Tilt: -135° to 80°
Roll: -230° to 95°
Pan: -25° to 25°

Controllable Range

Tilt: -90° to 55°
Roll: -180° to 45°

Max Control Speed (tilt)

100°/s

Angular Vibration Range

±0.005°

Sensing Type

Omnidirectional binocular vision system, supplemented with forward-facing LiDAR and an infrared sensor at the bottom of the aircraft

Forward

Measurement Range: 0.5-18 m
Detection Range: 0.5-200 m
Effective Sensing Speed: Flight Speed ≤ 15 m/s
FOV: Horizontal 90°, Vertical 72°

Backward

Measurement Range: 0.5-18 m
Effective Sensing Speed: Flight Speed ≤ 14 m/s
FOV: Horizontal 90°, Vertical 72°

Lateral

Measurement Range: 0.5-12 m
Effective Sensing Speed: Flight Speed ≤ 14 m/s
FOV: Horizontal 90°, Vertical 72°

Upward

Measurement Range: 0.5-18 m
Effective Sensing Speed: Flight Speed ≤ 6 m/s
FOV: Front and Back 72°, Left and Right 90°

Downward

Measurement Range: 0.3-14 m
Effective Sensing Speed: Flight Speed ≤ 6 m/s
FOV: Front and Back 106°, Left and Right 90°

Operating Environment

Forward, Backward, Left, Right, and Upward:
Surfaces with discernible patterns and adequate lighting (lux > 1)

Downward:
Surfaces with discernible patterns, diffuse reflectivity > 20% (e.g., walls, trees, people), and adequate lighting (lux > 1)

3D Infrared Sensor

Forward-Facing LiDAR
Measurement Range (nighttime): 0.5-25 m (reflectivity > 10%)
FOV: Up and Down 60°, Left and Right 60°

Downward-Facing Infrared Sensor
Measurement Range: 0.3-8 m (reflectivity > 10%)
FOV: Front and Back 60°, Left and Right 60°

Video Transmission System

O4+

Live View Quality

Remote Controller:
1080p/30fps, 1080p/60fps

Operating Frequency

2.400-2.4835 GHz
5.170-5.250 GHz
5.725-5.850 GHz

^{Operating frequency allowed varies among countries and regions. Refer to local laws and regulations for more information.}

Transmitter Power (EIRP)

2.4 GHz:
< 33 dBm (FCC)
< 20 dBm (CE/SRRC/MIC)

5.1 GHz:
< 23 dBm (CE)

5.8 GHz:
< 33 dBm (FCC)
< 30 dBm (SRRC)
< 14 dBm (CE)

Max Transmission Distance (unobstructed, free of interference)

FCC: 20 km
CE: 10 km
SRRC: 10 km
MIC: 10 km

^{Measured in an unobstructed outdoor environment free of interference. The above data shows the farthest communication range for one-way, non-return flights under each standard. Always pay attention to RTH reminders in the app during your flight.}

Max Transmission Distance (unobstructed, with interference)

Strong Interference: Urban landscape, approx. 1.5-4 km
Medium Interference: Suburban landscape, approx. 4-10 km
Low Interference: Suburb/Seaside, approx. 10-20 km

^{Measured under FCC standard in unobstructed environments with typical interference. Used for reference purposes only and provides no guarantee for actual transmission distance.}

Max Transmission Distance (obstructed, with interference)

Low Interference and Obstructed by Buildings: Approx. 0-0.7 km
Low Interference and Obstructed by Trees: Approx. 0.7-4.5 km

^{Measured under FCC standard in obstructed environments with typical low interference. Used for reference purposes only and provides no guarantee for actual transmission distance.}

Max Download Speed

O4+:
10 MB/s (with DJI RC-N3 Remote Controller)
10 MB/s (with DJI RC 2)
Wi-Fi 6: Up to 100 MB/s*

^{* Measured in a laboratory environment with little interference in countries/regions that support both 2.4 GHz and 5.8 GHz. Download speeds may vary depending on the actual conditions.}

Lowest Latency

Aircraft + Remote Controller: Approx. 120 ms

^{Depending on the actual environment and mobile device.}

Antenna

4 antennas, 2T4R

Protocol

802.11 a/b/g/n/ac/ax

Operating Frequency

2.400-2.4835 GHz
5.725-5.850 GHz

Transmitter Power (EIRP)

2.4 GHz:
< 20 dBm (FCC/CE/SRRC/MIC)

5.8 GHz:
< 26 dBm (FCC/SRRC)
< 14 dBm (CE)

Protocol

Bluetooth 5.4

Operating Frequency

2.400-2.4835 GHz

Transmitter Power (EIRP)

< 10 dBm

Capacity

DJI Mini 5 Pro Intelligent Flight Battery: 2788 mAh
DJI Mini 5 Pro Intelligent Flight Battery Plus*: 4680 mAh

^{* The Intelligent Flight Battery Plus is not sold in Europe.}

Weight

DJI Mini 5 Pro Intelligent Flight Battery: approx. 71.2 g
DJI Mini 5 Pro Intelligent Flight Battery Plus*: approx. 117 g

^{* The Intelligent Flight Battery Plus is not sold in Europe.}

Nominal Voltage

DJI Mini 5 Pro Intelligent Flight Battery: 7 V
DJI Mini 5 Pro Intelligent Flight Battery Plus*: 7.16 V

^{* The Intelligent Flight Battery Plus is not sold in Europe.}

Max Charging Voltage

DJI Mini 5 Pro Intelligent Flight Battery: 8.6 V
DJI Mini 5 Pro Intelligent Flight Battery Plus*: 8.6 V

^{* The Intelligent Flight Battery Plus is not sold in Europe.}

Battery Type

Li-ion

Chemical System

LiNiMnCoO2

Energy

DJI Mini 5 Pro Intelligent Flight Battery: 19.52 Wh
DJI Mini 5 Pro Intelligent Flight Battery Plus*: 33.51 Wh

^{* The Intelligent Flight Battery Plus is not sold in Europe.}

Charging Temperature

5° to 40° C (41° to 104° F)

Charging Time

DJI Mini 5 Pro Intelligent Flight Battery:
1 battery can be fully charged in approx. 69 minutes by charging through the drone using the DJI 65W Portable Charger.
1 battery can be fully charged in approx. 46 minutes using the Two-Way Charging Hub and DJI 65W Portable Charger.
3 batteries can be fully charged in approx. 115 minutes using the Two-Way Charging Hub and DJI 65W Portable Charger.

DJI Mini 5 Pro Intelligent Flight Battery Plus*:
1 battery can be fully charged in approx. 94 minutes by charging through the drone using the DJI 65W Portable Charger.
1 battery can be fully charged in approx. 56 minutes using the Two-Way Charging Hub and DJI 65W Portable Charger.
3 batteries can be fully charged in approx. 193 minutes using the Two-Way Charging Hub and DJI 65W Portable Charger.

<sup>Charging time is measured in a test environment with a temperature of 25°C. Actual charging time may increase due to higher ambient temperatures or variations in mains voltage between regions.
* The Intelligent Flight Battery Plus is not sold in Europe.</sup>

Input

USB-C: 5-15 V, max 4.3 A

Output

Battery Port: 5-15 V, max 2 A

Charging Type

DJI Mini 5 Pro Intelligent Flight Battery: Two batteries charged in parallel
DJI Mini 5 Pro Intelligent Flight Battery Plus*: Three batteries charged in sequence

^{* The Intelligent Flight Battery Plus is not sold in Europe.}

Compatibility

DJI Mini 5 Pro Intelligent Flight Battery
DJI Mini 5 Pro Intelligent Flight Battery Plus*

^{* The Intelligent Flight Battery Plus is not sold in Europe.}

Recommended microSD Cards

Lexar Silver plus 64GB A2 V30 microSDXC
Lexar Silver plus 128GB A2 V30 microSDXC
Lexar Silver plus 256GB A2 V30 microSDXC
Lexar Silver plus 512GB A2 V30 microSDXC
Lexar Silver plus 1TB A2 V30 microSDXC
Kingston CANVAS GO! Plus 64GB A2 V30 microSDXC
Kingston CANVAS GO! Plus 128GB A2 V30 microSDXC
Kingston CANVAS GO! Plus 256GB A2 V30 microSDXC
Kingston CANVAS GO! Plus 512GB A2 V30 microSDXC

DJI RC-N3 Remote Controller

Max Operating Time

Without charging any mobile device: 3.5 hours
When charging a mobile device: 1.5 hours

Max Supported Mobile Device Size

180×86×10 mm (L×W×H)

Operating Temperature

-10° to 40° C (14° to 104° F)

Charging Temperature

5° to 40° C (41° to 104° F)

Charging Time

2 hours

Charging Type

It is recommended to use a 5V/2A charger.

Battery Capacity

9.36 Wh (3.6 V, 2600 mAh)

Weight

Approx. 320 g

Dimensions

104.2×150×45.2 mm (L×W×H)

Supported Mobile Device Port Type

Lightning, USB-C, Micro-USB

^{Using a mobile device with a Micro-USB port requires the DJI RC-N Series RC Cable (Standard Micro USB Connector), which is sold separately.}

Video Transmission Operating Frequency

2.400-2.4835 GHz
5.170-5.250 GHz
5.725-5.850 GHz

^{Operating frequency allowed varies among countries and regions. Refer to local laws and regulations for more information.}

Video Transmission Transmitter Power (EIRP)

2.4 GHz:
< 33 dBm (FCC)
< 20 dBm (CE/SRRC/MIC)

5.1 GHz:
< 23 dBm (CE)

5.8 GHz:
< 33 dBm (FCC)
< 14 dBm (CE)
< 30 dBm (SRRC)
