Aputure Light Storm 60X
- 15°~45° Adjustable Spot/Flood Beam Angle
- Up to 50,000 lux+ (LS 60d) / 30,000 lux+ (LS 60x) @ 1 meter in full spot (15°)
- Color Temperature: 5600K(LS 60d), 2700K~6500K(LS 60x)
- Weatherproof (Dust and Water Resistant)
- Use One NP-F Battery for Half Power; Two for Full Power
- D-Tap Battery Operable
- V-Mount Receiver on Yoke
- Sidus Link Mobile App Control
- Custom Bowens Mount Adapter
- Compatible “Spotlight Mini Zoom” Projection Lens & “LS 60 Softbox”
The LS 60x is a battery-powerable daylight-balanced focusing LED that uses custom aspherical optics to achieve a 15-45° spot-flood beam angle with intense output and flexibility.
The LS 60x punches way above its weight class as a 60W Expanded Bi-Color Focusing LED fixture that outclasses the output of a 300W tungsten Fresnel and outpaces comparable LED lights. With its custom, Aputure aspherical optics, the LS 60x (@ 5600K) can output 30,000+ lux in full spot, or 5,200+ lux in flood mode.
Matching the LS 300x, the LS 60x features an expanded bi-color CCT range of 2700K-6500K, with built-in CCT presets, to give filmmakers the ability to add just a touch of warmer or cooler colors to their scene.
The LS 60x Bi-color LED continues Aputure’s ambition to provide high-quality, color-accurate LEDs to all filmmakers, with CRI/TLCI scores of 95+, and SSI (Tungsten) of 86, and an SSI (D56) of 74.
Designed to withstand the rigors of any film set, the LS 60x lamp head &DC power connector feature a weather-resistant design as a sign of its durability, so filmmakers can feel free to take it on any adventure.
With a variety of included power solutions, the LS 60x is a light designed to solve problems in ways no other fixture can. The modular V-Mount Receiver on its yoke can hold all of its power options, including the AC adapter, D-Tap (V-Mount) Batteries, and the intelligent Dual NP-F Battery Plate.
Light Storm fixtures like the 120d II, 300d II, and 300x can be powered using only a single battery, and the LS 60x is no different. The LS 60x can achieve full output with a single D-Tap battery or two NP-F batteries, or half output with a single NP-F battery, using its intelligent Dual NP-F Battery Plate.
Included with the LS 60x, the 8-Leaf Barndoors allow for more precise control than traditional barndoors due to the two pairs of helper flags that can adapt the light output’s size and shape.
BOWENS MOUNT ADAPTABILITY
As a Light Storm fixture, the LS 60x can utilize a wide variety of lighting modifiers. In addition to its 8-Leaf Barndoors, 60x includes a custom Bowens Mount Adapter that attaches to its accessory mount and allows it to use Bowens Mount soft light modifiers.
LIGHT SHAPING TOOLS
The LS 60x is also compatible with the LS 60 Softbox, a square soft light modifier, and the Spotlight Mini Zoom, a precision protection attachment with a 2X optical zoom range, both of which are designed specifically for the LS 60d & 60x.
BUILT-IN LIGHTING FX
The 60x launches with 9 built-in lighting FX, such as Paparazzi, Fireworks, Lightning, Faulty Bulb, TV, Pulsing, Strobe, Explosion, and Fire, with adjustable color temperature control.
SIDUS APP CONTROL
Joining the Sidus Link ecosystem, the LS 60x gains unprecedented, quick & easy wireless control for any fixture in its class. As part of a mesh network, the LS 60x conducts two-way communication with the controlling smartphone or tablet and all other Sidus Mesh fixtures, resulting in a more robust network and longer range.
What's in the box?
- 1 x Aputure Light Storm LS 60x Bi-Color LED Light
- 1 x LS 60x Lamp Head
- 1 x Barndoors
- 1 x Power Supply with Cable
- 1 x NP-F Battery Plate Adapter
- 1 x D-Tap Cable
- 1 x Carrying Case
- Beam Angle
- 95 (ave.)
- 74 (D56) ; 86 (Tungsten)
- Battery Type
- Operating Temperature
- -20°C ~ 45°C
- Operating Voltage
- 19V (Power Supply) ; 6~8.4V (Single battery) 12~16.8V (Dual battery) (Sony NP-F Battery) ; 12 ~ 16.8V (D-Tap Battery)
- Mount Type
- 16mm | 5/8in (Baby Pin)
- Accessory Mount
- LS 60 Mini Mount
- Active Cooling
- Remote Control
- On-board, Sidus Link (Sidus MeshTM)
- Max Power Consumption
- 60 W
- AC Input Power
- 100 to 240 VAC, 50 / 60 Hz
CCT 2700K : 1m 25,110 Lux/ 2,332 Fc ; 3m 3,125 Lux/ 290 Fc ; 5m 1,116 Lux/ 104 Fc
CCT 5600K : 1m 33,480 Lux/ 3,110 Fc ; 3m 4,241 Lux/ 394 Fc ; 5m 1,451 Lux/ 134 Fc
CCT 6500K : 1m 32,364 Lux/ 3,007 Fc ; 3m 4,018 Lux/ 373 Fc ; 5m 1,395 Lux/ 129 Fc
CCT 2700K : 1m 4,464 Lux/ 415 Fc ; 3m 525 Lux/ 49 Fc ; 5m 201 Lux/ 19 Fc
CCT 5600K : 1m 5,803 Lux/ 539 Fc ; 3m 703 Lux/ 66 Fc ; 5m 268 Lux/ 25 Fc
CCT 6500K : 1m 5,580 Lux/ 519 Fc ; 3m 670 Lux/ 61 Fc ; 5m 246 Lux/ 22 Fc
Lamp Head without Yoke
Lamp Head with Yoke
Barn Doors Closed
NP-F Battery Plate
NP-F Battery Plate
Total w/ Case
- Limited 1-Year Warranty
