[PRE-ORDER] Deity PR-4 Compact Field Recorder
Product Highlights
- 4 Inputs / 6 Tracks (2x XLR, 1x TRS)
- 2 Outputs (2x Balanced or 4 Unbalanced)
- 32-Bit Float Recording
- Up to +60 dB of ultra-clean gain
- Automatically mixes multiple microphones
- Record simultaneously on a SD card up to 1TB + internal 64GB SSD
- Sync slates, recorders and timecode boxes directly from the recorder
- Remote monitoring and control via smartphone or tablet
- Color Touchscreen Interface
- Compatible with professional digital microphones and gear
Route different signals to cameras, headphones, or mixes
NP-F Battery Compatible
![[PRE-ORDER] Deity PR-4 Field Audio Bag (Mini)](/_next/image?url=https%3A%2F%2Fassets.cathayphoto.com.sg%2Fproduct%2F_680x571_crop_center_none%2FDEI-ZZ-PR-4_BM_CRAFT_01.jpg&w=3840&q=75)
![[PRE-ORDER] Deity NP-F550 Rechargeable Lithium-Ion Battery (3350mAh)](/_next/image?url=https%3A%2F%2Fassets.cathayphoto.com.sg%2Fproduct%2F_680x571_crop_center_none%2FDEI-ZZ-NP-F550_CRAFT_01.jpg&w=3840&q=75)
SIX TRACKS. POCKET-SIZED.
PR-4 is a compact, foward-facing recorder for doc, ENG, and video creator workflows—delivering 32-bit float performance, 4 inputs / 6 tracks, wired SMPTE LTC/ATC plus wireless timecode for DEITY’s ecosystem, and Sidus App control for integrated full wireless remote control.
Introducing the ReGain PreAmp™
The PR-4 features the brand new ReGain Preamps™, ultra-quiet microphone preamps that deliver up to 60 dB of gain, providing enough amplification to drive even demanding dynamic microphones without the need for external inline boosters.
Achieving an Equivalent Input Noise of -127 dBV (-125 dBu) represents a significant engineering accomplishment for the PR-4’s preamp design. Measured under A-weighted conditions at 60 dB gain with a 150 ohm source, this level of performance places the PR-4 firmly in professional territory, delivering an exceptionally low noise floor that preserves detail and clarity even with low-output microphones.
Introducing the VoiceAware Automix™
VoiceAware Automix™ intelligently manages multiple microphones in real time, dynamically prioritizing active voices while subtly reducing the presence of inactive channels. By continuously analyzing incoming signals, it maintains a clean and focused mix that minimizes ambient buildup and keeps dialogue clear and intelligible, even in multi-speaker environments.
The result, VoiceAware Automix™ creates a clean, well-balanced stereo reference mix for post-production, giving editors a helpful starting point.
I/O Built for Real-World Shoots
Input
2× XLR (Mic, +48V, Line, AES3, AES42)
Stereo 3.5 mm TRS
Outputs
2x Stereo 3.5mm TRS Main Outputs
3.5mm Timecode I/O
3.5mm Headphone
Routing
Output 1 & 2 Matrix
Headphone Matrix
L / R Mix Track Matrix
True Dual Media
Using a dedicated recorder like the PR-4 with dual media recording helps protect against some of the most common data-loss scenarios in production. SD cards can be lost, corrupted, or accidentally formatted during a busy shoot or when offloading media at the end of the day. By recording simultaneously to both an SD card (up to 1TB) and the internal 64GB SSD, the PR-4 provides a built-in safety net, ensuring there is always a second copy of your audio even if something happens to the primary card.
We also allow you to record different signals to each media format. Client ask for just a stereo file? You can still record the POLY file as a backup… just in case.
+8 Hrs Battery Life
The PR-4 runs on rechargeable power.
The PR-4 features an internal NP-F550 battery bay that can be recharged via the USB-C port on the side of the unit. It also can just run off the USB-C port if you want, making external power options cheap and readily available.
For the professional looking to integrate the PR-4 into a bigger setup, there is a 4-Pin Push Pull Power port on the other side of the unit that is compatible with the SPD-1, SPD-Mini, or can be fed direct power form the S-95 using the SPD-HRBatt. It too can also be used to recharge the internal L-series battery.
Introducing LiveHit DeNoiser™
LiveHit DeNoiser is designed to prioritize intelligibility in real-world recording conditions by actively shaping the audio signal around the human voice. And it does all that without adding measurable latency to your audio.
It focuses on reducing ambient distractions like traffic, wind, and environmental rumble while preserving the core presence and clarity of the speaker. The result is a reporter’s microphone track that cuts through the mix, helping operators capture usable dialogue even when live broadcast in uncontrolled environments.
Rear Tally Light
The PR-4 can also function as a compact audio interface for cameras, allowing multiple microphones to be mixed and sent directly into the camera as a clean, mixed signal.
AES3/AES42 Support
Quad RX units typically require AES3 support to achieve all 4 channels. Making the PR-4 a perfect pairing with a Quad RX.
Automated Sound Reports
Automatically logging every session and embedding critical metadata directly into each file, to both the SSD & SD Card.
Stay Organized Going Into Editing
We give you metadata control over; Folder Name, Scene / Take File Name & Preset Notes per File
POLYWave File Support
No longer will you have to juggle multiple mono or stero tracks. Polywave support and Track names work in your favorite video editing software.
World’s First Recorder to Natively Wirelessly Sync A Timecode Boxes & Slate
The goal has always been for the recorder to be the TC master source on a video shot, now it truly is.
The PR-4 is able to act as the master timecode generator for a small production team. Through our wireless timecode protocol, the PR-4 is able transmit it’s timecode to our entire timecode ecosystem of devices:
- DBTX Transmitter
- DXTX XLR Transmitter
- DLTX Lemo 48V Transmitter
- PR-2 Pocket Recorder
- PR-2ii Pocket Recorder
- TC-1 Timecode Box
- TC-SL1 Timecode Slate
And of course… other PR-4 units
The PR-4 also features a 3.5mm TC I/O port. Timecode jam a camera and other gear with SMPTE LTC/ATC.
Accuracy target: <1 frame / 48 h.
Or wirelessly sync using via the Sidus Audio App on Apple App Store and Google Play.
What's in the box?
- 1 x PR-4 32-Bit Float 4-Input Audio Recorder
- 1 x User Manual QR Code
- 1 x Sidus Audio Download QR Code
- 1 x Warranty Card
- 1 x Deity Stickers
- Sampling Rate
- 48kHz, 96kHz, 192kHz
- Bit Depth
- 24bit. 32bit, 32bit Float
- Recording Formats
- .WAV
- Built In Microphone
- None
- Build In Speaker
- None
- SSD Storage Card
- Built-In 64G
- Supported SD Cards
- up to ITB
- Time Code
- LTC/ATC/Wireless Timecode
- TC FPS
- 23.98F, 24F, 25F, 29.97F, 29.97DF, 30F, 47.95F, 48F, 50F, 59.94F, 59.94DF, 60F
- Analog Input Channels
- 4
- Analog Output Channels
- 2
- Digital Input Channels
- 4
- Digital Output Channels
- 0
- USB Audio I/O Channels
- 2 Outputs
- Headphone Monitor Channels
- 1
- Recommended Headphone Impedence
- >16Ω
Input
- Phantom Power
- 48V
- Maximum Input Level
- Line 24dBu; Mic 11 dBu
- Input Gain Range
mic /48V/AES42: 0 ~ +60dB
line: -20 ~ +30dB
AES3: -20 ~ + 40dB
- Input Impedence
XLR (Mic): 1.5kΩ or more;
XLR (Line): 4kΩ or more;
3.5mm (Mic): 2kΩ or more
3.5mm (Line): 3kΩ or more
- Input Frequency Response
- 20 - 80kHz (192kHz Sample Rate)
- Input Dynamic Range
- 137dB
- Input Noise Floor (EIN)
- -127dBV(mic in, A-weighted, Gain 60dB, Load Impedance 150Ω)
- THD+N
- 0.005%
Output
- Maximum Output Level
- Line: 8dBu; Headphone: 8dBu
- 64G SSD Recording Time / Single Track
(The following times are estimates. When multi-track recording is enabled. recording times decreases proportionally)
.WAV 48kHz/24 Bit ≈ 113 h
.WAV 48kHz/32 Bit (or 32 Bit F) ≈ 86 h
.WAV 96kHz/24 Bit ≈ 56 h
.WAV 96kHz/32 Bit (or 32 Bit F) ≈ 42 h
.WAV 192kHz/24 Bit ≈ 28 h
.WAV 192kHz/32 Bit (or 32 Bit F) ≈ 21 h
Power
- Power Options
- NP-550 Battery, Hirose-4Pin, USB-C
- Battery Life
- ≈ 8.5h (F55)
- Voltage
- NP-550 7.3V; DC 12-18V; USB-C 5/9/12V
- Current
- NP-550 360mA; DC 220mA(14.4V); USB-C 520mA
- Power
- NP-550 2.62W; DC 3.16W; USB-C 2.6W
Physical
- Dimensions
- 98 x 80 x 41mm (H x W x D)
- Weight
- 218g (without battery)
- Operating Temperature
- -20 °C - 50°C
